2000–2006 Toyota Tundra 3.5-Inch Long-Travel Suspension Kit with Boxed Control Arms

Description

PRODUCT OVERVIEW:

Total Chaos Fabrication 3.5″ boxed long travel kit for the 2000-2006 Toyota Tundra is constructed out of 4130 chromoly and is manufactured in the U.S.A

SPECS:

KEY FEATURES:

• 3.5″ extended 4130 chromoly tubular upper and lower control arms bolt to factory mounting locations.
• Upper ball joints are replaced with 1″ uniballs for maximum travel and component strength.
• TOTAL CHAOS includes 1″ I.D. uniballs that feature a heat treated stainless steel ball & heat treated stainless steel race for maximum corrosion resistance and component longevity. These uniball’s also features a military grade PTFE woven fabric liner that helps prevent noise.
• TC’s original tubular/plated lower control arms are designed with internal gussets and feature dual 2.5″ shock capability.
• A secondary external bypass shock can be installed to increase dampening and tune-ability.
• Spring rate options offer the ability to customize your ride for your specific application allowing you to maximize tune ability and performance.
• Adjustable limit strap clevis’ are included so that you can properly limit the suspensions droop wheel travel and make necessary adjustments during the life of the limit strap.
• Stainless steel DOT braided brake lines, TC custom 17-4 stainless hi-misalignment spacers and all grade 8 mounting hardware is included.
• TC 4340 custom extended axles reuse factory inner and outer CV’s to retain 4wd.
  (axles are sold separately and not included with the kit)
• 2 stage powder coat process includes a durable clear coat to provide a long lasting finish.

TECH NOTES:

• 2.5″ long travel specific coil over shocks bolt into the factory coil bucket location. Extended travel shocks are too short and will not work.

• BRAND	COILOVER PART#	BYPASS PART#
  FOX	883-02-065	982-02-954
  KING	TC5151-03	TC1151-34

• Fiberglass fenders are required.
