CST Lift Kit for 2011–2019 & 2020+ GM 2500/3500 – FOX 2.5 HTO Suspension System (1–4 Inches)

Description

Description:

The latest additions to our line of Fox-Series CST Suspension Systems all include the new 2.5 Performance Series HTO shocks from Fox. These new Hydraulic Top Out (HTO) shocks provide all of the added features of a 2.5 shock at 2.0 prices, allowing us to offer CST Suspension Systems in an even more appealing price range. (shock details below)

CST Leveling Kits Include:

• Forged Kryptonite Torsion Keys
• CST Pro-Series UCA’s w/ High-Angle Ball Joints
• Fox 2.5 HTO Shocks (2 front/2 rear)

Leveling Kit Features:

• CST Pro-Series UCA w/ O.E. style rubber bushings at the frame to reduce noise
• CST High-Angle Ball Joints provide as much movement as a Uniball
• Ball Joints can be serviced (zerk under billet cap)
• Lifetime Warranty on CST Rubber Bushings & High-Angle Ball Joints
• Forged Torsion Keys

HTO Shock Features:

• 2.5 Impact extruded 6061-T6 alum. shock body
• Type II clear-anodized body plating
• High-flow velocity-sensitive damping
• 5/8″ hard chrome plated shaft
• Internal floating piston (IFP)
• Hydraulic Top Out (HTO) featured
• HTO reduces harsh top-outs
• HTO Increases comfort by forcing shock oil through a secondary shim stack to slow down shock shaft speed
• HTO is particularly beneficial after installing heavier, aggressive tires in lifted applications
