SDHQ ’22–’25 Tundra ARB Dual Compressor Mounting Kit

Description

This SDHQ Built Compressor mounting kit is only compatible with the standard arb twin compressor (Non-brushless)

Features:

• 3D CAD designed for a precise fit and finish
• Fits 2022-2025 Tundra Non-Hybrid and Hybrid*  (*8ft Bed not tested)
• Fits ARB Twin Air Compressors
• Not compatible with ARB Single Air Compressors or Viair Air Compressors
• No drilling required
• Includes Class 10.9 steel hardware
• Fabricated from 1/4″ sheet metal for durability
• Bolts directly into the rear of the frame rail on the passenger side.
• Ships powder coated black.
• Not compatible with 00-1103-SM, 00-1103-ACM or 00-1103-ACSM.
• Difficulty of Installation: Easy
• Install Time: Approx. 1 Hour (not including wiring)

🔧 INSTALL INSTRUCTIONS 🔧

Product options:

Filter Relocation Kit (SDHQ-50-1103-FR):

• • 3D CAD designed for a precise fit and finish
  • Designed to work specifically with ARB Twin Air Compressors
  • Not compatible with ARB Single Air Compressors or Viair Air Compressors
  • Requires no drilling for installation
  • Includes high-quality hardware made of Class 10.9 steel and 18-8 stainless steel
  • Uses industry-standard 3/8″ push-to-connect cartridges
  • Incorporates bronze air filters for added protection
  • Utilizes a billet aluminum block to house the filters and cartridges
  • Features a corrosion-resistant and strong stainless steel bracket
  • Superior water, mud, and dirt protection (mounts above bed support behind the taillight on Tundra)
  • Easy to install (approximately 1 hour)

7.5′ Air Chuck/Switch Mounting Kit (SDHQ-00-1104-BK1):

• • 3D CAD designed for a precise fit and finish
  • Designed to fit vehicles equipped with a rear-mounted air compressor.
  • Drilling is required for installation.
  • Perfect for mounting an air chuck in the rear bumper or in the bed of a truck.
  • Utilizes a Recessed Air Chuck Bulkhead (00-1104-BH1)
  • Includes 7.5ft 3/8″ Airline Kit (00-1004-38-075)
  • Includes Recessed Switch Mount (00-1103-RSM)
  • Some Molle Panels may interfere with mounting in the bedside
  •  22+ Tundra with Inverter Option – Built Right Panels interfere
  • Difficulty of Installation: Easy
  • Install Time: Approx. 1 Hour (not including wiring)

ARB Twin 10′ Switch Wiring Kit (SDHQ-02-1103-ARB-S2):

• • Connects ARB Twin Compressor to ARB switch (included w/ compressor)
  • Comes pinned for ARB Switch
  • Extra wires, terminals, and connector included for wiring to an ARB switch
  • Built with Premium Materials
  • TXL Cross-Linked Wire
  • Flexo braided Loom
  • DSG Dual Wall Heat Shrink Tubing
  • Not compatible with ARB air locker wiring harness

ARB Twin 10′ Switch-Pros Connect Wiring (SDHQ-02-1103-ARB-SP):

• • Connects ARB Twin Compressor to Switch-Pros style 12v trigger output
  • Comes pinned for Switch-Pros style trigger
  • Built with Premium Materials
    • TXL Cross-Linked Wire
    • Flexo braided Loom
    • DSG Dual Wall Heat Shrink Tubing
  • Not compatible with ARB air locker wiring harness
  • When selecting this option from the drop-down menu, it will also include a recessed air chuck kit (SDHQ-00-1104-BH1) and our SDHQ Built universal air line kit to plumb from the compressor to the air chuck!

ARB Twin 20′ Switch Pros Trigger Kit (SDHQ-02-1103-ARB-SPX):

• • Connects ARB Twin Compressor to Switch Pros style 12v trigger output
  • Comes pinned for Switch Pros style trigger
  • Built with Premium Materials
    • • TXL Cross-Linked Wire
      • Flexo braided Loom
      • DSG Dual Wall Heat Shrink Tubing
  • Not compatible with ARB air locker wiring harness
  • When selecting this option from the drop-down menu, it will also include a recessed air chuck kit (SDHQ-00-1104-BH1) and our SDHQ Built universal air line kit to plumb from the compressor to the air chuck!
